How you can connect Megabytes STAR compact C4 inside a wireless infrastructure

                  How you can connect Megabytes STAR compact C4 inside a wireless infrastructure

    I didn't include steps make it possible for Road24h peer to see network mainly because this method works very well in my needs.

1. You are able to set your router to possess any SSID title. I set mine as workshop, I actually do suggested you to employ a network type in the next format A123456789365 the amount portion could be any combination. I've examined using various SSID names and then any appear to operate fine

2. Visit start menu, programs, service, setup Sdnet control and run it, once finished pc will reboot, I additionally suggest you remove the configuration in the SD connect. this really is to begin fresh.

3. Visit F:programmeDasbin and open the cal.ini file, you will have to modify from either T or D2 to W.

4. Be sure all Wi-fi compatability and Lan motorists are set up which you're attached to the wi-fi compatability network you'll be using. (Throughout this whole process you need to monitor the wi-fi compatability status as it features a inclination to disconnect sometimes)

5. we currently have to obtain some fundamental info out of your network, visit start menu, configurations, user interface and open network connections, double click on the wireless network connection once window is open click support tab you will have to write lower the Ip and also the default gateway of the system therefore we can enter them later in SDNC.

6. Now visit the SDNC user interface by clicking the SDconnect icon once, after it's open choose the configuration tab, click yes within the window that opens, now visit network, once open start at the end, for country configurations leave them set to world, For Road WLAN enter values below: Ip: 192.168.2.222 Subnet mask: 255.255.255. Network title: (ssid) Road24h Network authentication: open (wep128) Choose hexadecimal and enter 26 lowercase a

7. Let's focus on Workshop WLAN Look into the box to Instantly obtain Ip, enter your network title [SSID] mine is workshop enter Network authentication: WPAPSK [TKIP] a123456789012

8. Workshop cable network enter following values: Ip: 169.254.214.163 subnet mask: 255.255.. Once complete click ok.

9. next we have to by hand set the Ip for that SDconnect, this can override the steps we required in item 8 above, we joined the 169 IP only therefore it would let us save another changes we made within SDNC, when the IP was wrong we're able to not save any changes. Open user interface then network connections. double click neighborhood connection, within the window labeled ;this connection uses the next products: search for Ip Address (TCP/IP) usually at bottom and double click it choose Get the Ip instantly and click on ok. now return and click on Ip Address (TCP/IP) again now choose Make use of the following Ip and enter 172.29.127.112 hit the tab answer to auto complete the subnet mask and click on ok then ok once more around the open window, when complete that window will instantly close might take a couple of moments for that IP in order to save and register. also make certain the wi-fi compatability connection continues to be linked to your network, it might disconnect as we enter values in SDNC

10. Now we have to energy in the SDconnect utilizing a 12v source. and fasten towards the pc via LAN cable, once it's powered up you will have to register/configure SDconnect. do that by visiting the taskbar and then click the SDconnect icon once to spread out it. Once open click Configuration tab then click yes around the pop-up window, next visit the MUX tab then click Register/configure this can open the SDconnect tool resource. Once open you are able to customize the configurations that will permit wireless communication. first select a number for the SDconnect, I personally use 9, next region choose WORLD, place a cheque mark within the square alongside WLANprameters,workshop, also place a cheque mark within the box to right from the DHCP line, go into the laptop you use Ip, within my situation it had been 192.168..9 then enter router IP under Gateway which within my situation was 192.168..1. for SSID [router title] enter title of the wi-fi compatability network, as mentioned earlier mine is workshop, in my file encryption I made use of WPA2 / ASCII my secret is A123456789365, in the end is joined click on the start tab, a window showing saved configuration displays click ok then close on SDconnect tool resource window. 11. You can look at connection by unplugging the LAN cable from PC or SDconnect then click on the number near the pad lock icon, when window opens click on the test signal tab you need to hear an audible beep from SDconnect unit. in certain situations this area near the SDconnect icon is going to be gray having a red-colored X you have to click on the gray box and choose your Megabytes SD Connect Compact 4, connect in the list.
